Operating manual
CNC 8070
USER TABLES
15.
(REF: 1505)
·239·
Operations with tables
15.5.2 Save and recall tables
Save a table.
1 Select the destination folder.
2 Define the file name at the bottom window. To replace an existing file, select it from the list.
3 Press [ENTER] to save the file or [ESC] to return to the table without saving the file.
Depending on the table being saved, the CNC will assign one of the following extensions
to the file:
Recall a table.
1 Select the folder containing the file.
2 Select the file from the list or write its name in the bottom window.
3 Press [ENTER] to recall the data from the file or [ESC] to return to the table without
recalling the data.
This softkey is used to save the table data, in ASCII format, in a file. After selecting the table
whose data is to be saved, press the "Save" softkey and the CNC shows a list with the tables
that are already saved. To save the table data, proceed as follows:
Extension. Table type
*.UPO Zero offset table.
*.UPF Fixture table.
*.UPP Arithmetic parameter tables.
This softkey is used to restore the table data from an ASCII file. After selecting the table
whose data is to be restored, press the "Load" softkey and the CNC shows a list with the
tables that are already saved. To recover the table data, proceed as follows:
