Fagor CNC 8070 - Program simulation and execution.

Operating manual
CNC 8070
AUTOMATIC MODE
4.
(REF: 1505)
·73·
Program simulation and execution.
4.3 Program simulation and execution.
4.3.1 Select program.
The CNC allows selecting and executing a different program in each channel. Each channel
executes the program selected in it. To select a program, press one of the following softkeys
of the vertical menu.
Once a program has been selected, its name appears on the general status bar. For each
channel, it shows the name of the program selected in that channel.
Softkey. Meaning.
This softkey shows the list of available programs. See
"3.7 File selection window" on page 61.
This softkey selects directly the program being edited in the
same channel.
