Operating manual
CNC 8070
AUTOMATIC MODE
4.
(REF: 1505)
·71·
Interface description.
4.1.1 Softkey menus.
Horizontal softkey menu.
When selecting the program screen, the horizontal softkey menu shows the following
options.
Vertical softkey menu.
The vertical softkey menu always shows all the options associated with this operating mode
regardless of the active screen.
Softkey. Description.
Starting block Set the first block of the execution.
Stop condition. Set the condition to end the execution or the manual block search.
Block search Recover the program history up to a particular block and resume
execution from that block on.
Exblk. Execute only the block selected with the cursor.
Active subroutines. Toggle between the display of program blocks and the display of
information related to the status of the subroutines, canned cycles,
repetition blocks and loops.
Simulated execution. Show the available simulated execution modes.
Find text. Find a line or a text in the program.
Softkey. Description.
Select a program for execution.
Begin tool inspection. Tool inspection is only available when program execution is
interrupted.
End simulated execution and start executing the program
Select the program that is being edited.
