Operating manual
CNC 8070
TOOL AND MAGAZINE TABLE
16.
(REF: 1505)
·263·
Operations with the tool table (full mode).
16.5 Operations with the tool table (full mode).
16.5.1 Editing the tool table
Initialize table
The table can only be initialized when the CNC is "READY". The table is initialized from the
vertical softkey menu.
Adding/removing a tool to/from the list
A tool may be added or deleted only when it is selected on the tool list. Both operations are
carried out from the vertical softkey menu.
Data editing
Proceed as follows to fill out the tool table data:
1 Select the tool to be set from the list and press [ENTER] to access its data.
2 Configure the table to show only the data that may be defined hiding the rest.
3 Define the tool data. Every time a new value is defined, press [ENTER] to validate it.
When a tool has several offsets, all the data of an offset may be copied to another offset.
This operation is carried out from the softkey menu.
4 Make a safety backup copy of the tool data out to a file.
When resetting the table, all the tools are deleted from the list, including those
in the spindle and on the tool changer arm. It also initializes the active-tools table
and the magazine tables because the available tools have been erased.
Add a tool to the list.
It adds a new tool to the list. The tool is added to the list at the first free position.
Remove a tool from the list.
It removes a tool from the list. A tool cannot be removed if it is in the magazine,
in the spindle or on the tool changer arm.
These softkeys may be used to copy on to the clipboard the data
of the offset being displayed and then paste it to another offset.
Key. Meaning.
Move the cursor through the table data.
Accept the new value.
Activate/deactivate the selection box.
Open/close pop-up menus.
Move the cursor within a data.
Select the line before or after the comment.
Move the cursor to the beginning or end of the comment line.
