Operating manual
CNC 8070
GENERAL CONCEPTS
2.
(REF: 1505)
·47·
Ethernet.
2.3 Ethernet.
The CNC must be configured as any node of the network as if it were a regular PC. The
following actions are possible when having a CNC configured as a node within the computer
network:
• Access from any PC to the part-program directory of the CNC.
• Access from the CNC to any PC, to execute, simulate or edit programs. The program to
be executed needs not be in the local disk.
• Copy programs and tables from the CNC to a PC and vice versa.
• Edit, modify, delete, rename, etc. the programs stored at the CNC.
• Perform a telediagnosis of the CNC.
2.4 USB.
Ethernet support for the following features, through the connector of the central unit.
• Point-to-point connection.
• Microsoft company networks.
• Internet for telediagnosis.
• TeamViewer server.
USB support for the following devices.
• Pendrive.
• Keyboard and mouse.
DO NOT connect any kind of hub to the USB port.
