Horizontal softkey menu
3.3 Horizontal softkey menu
The machine manufacturer may have configured how to use the horizontal softkey menu
(parameter SFTYPE) in one of the following ways.
Standard softkey menu.
Softkey tree based on menus and submenus, i.e. there are different softkey levels within the
same work mode. To return to the main menu, press the [BACK] key (previous menu).
Pop-up softkey menu.
Softkey tree based on popup menus so there is only one softkey level. There are no softkey
submenu, which simplifies the operation.
Key. Meaning.
Previous menu.
The softkey menu expands and shrinks with keys [F1] through
[F7]. The softkey of the pop-up menu are selected with the
[ENTER] key or from the numeric keypad using the number that
comes with each softkey.
BACK
