Fagor CNC 8070 - Configuring network properties.

To Next Page

To Previous Page

·412·

Operating manual

CNC 8070

23.

APPS

(REF: 1505)

Send emails.

23.1.2 Configuring network properties.

If the user wants to access remote resources (servers external to the local network), he must

configure the network properties of the CNC in a matching the configuration of the local

network where the unit is installed. In Diagnosis mode, expand the softkey Apps > Apps >

Network Settings.
