Operating manual
CNC 8070
MACHINE PARAMETERS
19.
(REF: 1505)
·341·
Operations with tables
19.3.2 Save and recall tables
Save a table.
1 Select the destination folder.
2 Define the file name at the bottom window. To replace an existing file, select it from the list.
3 Press [ENTER] to save the file or [ESC] to return to the table without saving the file.
The files are saved with the extension *.MP.
Recall a table.
1 Select the folder containing the file.
2 Select the file from the list or write its name in the bottom window.
3 Press [ENTER] to recall the data from the file or [ESC] to return to the table without
recalling the data.
This softkey is used to save the table data, in ASCII format, in a file. Use the softkey menu
to select the table whose data is to be saved. If no table is selected, all the data of all the
tables will be saved. After selecting the table whose data is to be saved, press the "Save"
softkey and the CNC shows a list with the tables that are already saved. To save the table
data, proceed as follows:
This softkey is used to restore the table data from an ASCII file. Use the softkey menu to select
the table whose data is to be recalled (restored). If no table is selected, all the data of all the
tables will be recalled. After selecting the table whose data is to be restored, press the "Load"
softkey and the CNC shows a list with the tables that are already saved. To recover the table
data, proceed as follows:
