Operating manual
CNC 8070
USER TABLES
15.
(REF: 1505)
·237·
Arithmetic parameter tables
Arithmetic parameters
The OEM defines the range of local and global parameters up to a maximum of 100 local
parameters (P0-P99) and 9900 global parameters (P100-P9999).
When the local parameters are used in a subroutine calling block, they can also be referred
to by the letters A-Z (except "Ñ") in such a way that "A" is the same as P0 and "Z" is the same
as P25. That is why the local parameter tables show the parameter number next to their
associated letter.
The parameter values may be set directly in the table or from the PLC or via part-program.
In this case, the table values are updated after carrying out the operations indicated in the
block being executed.
The parameter values may be displayed either in decimal notation (6475.873) or scientific
(0.654E-3).
