·64·
Operating manual
CNC 8070
3.
HOW TO OPERATE THE CNC
(REF: 1505)
Calculator
Softkey menu
The softkey menu shows all the available operations. The expressions may be edited using
either the softkey menu or the mouse with the calculator keys.
Work units
The result of the operations may be given in various units. Use the following icons to change
the units. It highlights the units currently selected.
Hexadecimal ($), decimal (D) or binary (B) units.
Units in degrees or radians.
