·84·
Operating manual
CNC 8070
4.
AUTOMATIC MODE
(REF: 1505)
Program simulation and execution.
Tool and offset.
Blocks with T and D programming (next tool and offset) are ignored during the retrace
function. Blocks with D programming (change of active tool offset) cancel the retrace
function.
·M· functions.
The behavior of the retrace function when executing M functions depends on how the
machine manufacturer has set it up. When the CNC finds an M function, it can either ignore
it and keep executing blocks in retrace or cancel the "retrace" function. In any case, the
following M functions behave as follows.
• Functions M00 and M01 are always executed; they are sent to the PLC and [CYCLE
START] must be pressed to resume execution in retrace.
• Functions M03 and M04 are always ignored; the CNC does not start the spindle nor does
it change its turning direction.
• While the spindle is running, function M05 cancels the "retrace" function; the CNC does
not stop the spindle. If the spindle was stopped, this function is ignored.
• Functions M19, M41, M42, M43 y M44 cancel the retrace function.
Functions that cancel the retrace function.
Definition. Functions and instructions.
Gear change. M41 M42 M43 M44
Spindle orientation. M19
Effective spindle stop. If the spindle was stopped, this
function does not cancel the retrace function.
M5
Change of work plane. G17 G18 G19 G20
Changing zero offset and fixture offsets, etc.
Functions G53-G59, G159 only cancel the retrace function
if they cancel an active zero offset.
G92 G158 G53-G59 G159
Probing. G100 G101 G102
#SELECT PROBE.
Activate, cancel or modify constant surface speed. G96 G97
"C" axis.
The instruction #CAX OFF only cancels the retrace function
if it cancels an active #CAX.
#CAX ON #CAS OFF
#FACE ON #FACE OFF
#CYL ON #CYL OFF
Tapping. G33 G63.
Changes in feed-forward or in AC-forward. G134 G135
Home search. G74
Changing the parameter set. G112
Changing the software limits. G198 G199
Synchronizing. #SYNC
High speed machining. #HSC ON #HSC OFF
Incline axis.
Freezing (suspending) an incline axis does not cancel the
retrace function.
#ANGAX ON #ANGAX OFF
Slaving axes. #LINK #UNLINK
Axis parking. #PARK #UNPARK
Tangential control. G45 G145
#TANGCTRL ON
#TANGCTRL OFF
#TANGCTRL SUSP
#TANGCTRL RESUME
Axis swapping. #SET AX #CALL AX #PUT AX
#RENAME AX
