Fuji Xerox Color 550

Alignment Adjustment Settings
285
Appendix
8
14 Press [Confirm].
15 Press [Close].
16 Check the sample printout, and adjust the position if misalignment has occurred.
For details on making each adjustment, refer to the following sections.
z
For skew adjustment, refer to "Skew Adjustment" (P.286).
z
For perpendicularity adjustment, refer to "Perpendicularity Adjustment" (P.287).
z
For scale position adjustment, refer to "Scale Adjustment" (P.288).
z
For print position adjustment, refer to "Print Position Adjustment" (P.289).
17 After you finish making adjustments, print another sample printout with [Sample
Printout] and check the adjustment results.
18 Make adjustments again if necessary. (Step 13)
19 Press [Save].
20 Press [Close].
21 Select the tray to apply the alignment
adjustment type that you just saved (the tray
which you loaded paper in Step 1), and then
press [Change Settings].
22 Select the adjusted alignment type and
press [Save].
