Replacing Consumables
59
Maintenance
3
1 Remove the new drum cartridge and the
supplied black sheet from the box
beforehand.
Important • Place the new drum cartridge on a level
surface.
• Do not place the new drum cartridge in an
upright position.
2 Make sure that the machine is not operating,
and open the front cover.
3 Pull down lever R1-R4 towards you.
4 Hold the handle of the unit and pull it out.
5 Cover the upper surface of the unit other
than drum cartridge R1 using the supplied
black sheet removed from the box earlier.
Important • When replacing a drum cartridge, be sure
to cover the unit with the black sheet.
Leaving it uncovered may degrade the
image quality.
Be sure to pull out the unit slowly. If pulled
out with too much force, it may hit and
injure your knees or other parts of your
body.
To Next Page
