Fujitsu PRIMERGY TX1310 M3

100 Upgrade and Maintenance Manual TX1310 M3
System fans
Figure 44: Installing the rear fan
Ê Lead the loose ends of the rubber rivets through the four screw holes on the
new rear fan.
Ê Pull tight until the expanding plug on the rubber rivet engages with the fan
(see close-up).
I Ensure that the expanding plugs on all four rubber rivets are securely
seated on the fan.
