Fujitsu PRIMERGY TX1310 M3 Upgrade And Maintenance Manual

TX1310 M3 Upgrade and Maintenance Manual
Contents
10.4 Replacing memory modules . . . . . . . . . . . . . . . . . . 128
10.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 128
10.4.2 Removing the defective memory module . . . . . . . . . . . . 128
10.4.3 Installing the new memory module . . . . . . . . . . . . . . . 128
10.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 128
11 Processor (CPU) . . . . . . . . . . . . . . . . . . . . . . . . 129
11.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 130
11.2 Upgrading or replacing the CPU . . . . . . . . . . . . . . . 131
11.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 131
11.2.2 Removing the heat sink . . . . . . . . . . . . . . . . . . . . . 132
11.2.3 Removing the CPU . . . . . . . . . . . . . . . . . . . . . . . 135
11.2.4 Installing the CPU . . . . . . . . . . . . . . . . . . . . . . . . 138
11.2.5 Applying thermal paste . . . . . . . . . . . . . . . . . . . . . 141
11.2.6 Installing the heat sink . . . . . . . . . . . . . . . . . . . . . . 143
11.2.7 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 145
11.3 Replacing the heat sink . . . . . . . . . . . . . . . . . . . . 147
11.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 147
11.3.2 Removing the heat sink . . . . . . . . . . . . . . . . . . . . . 147
11.3.3 Installing the heat sink . . . . . . . . . . . . . . . . . . . . . . 147
11.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 147
11.4 Handling the protective cover . . . . . . . . . . . . . . . . . 148
11.4.1 Installing the protective cover . . . . . . . . . . . . . . . . . . 148
11.4.2 Removing the protective cover . . . . . . . . . . . . . . . . . 151
12 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 155
12.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 156
12.2 Optical disk drive (ODD) . . . . . . . . . . . . . . . . . . . . 157
12.2.1 Installing an ODD . . . . . . . . . . . . . . . . . . . . . . . . 157
12.2.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 157
12.2.1.2 Removing the dummy cover bay 1 . . . . . . . . . . . . . . 157
12.2.1.3 Preparing the ODD . . . . . . . . . . . . . . . . . . . . . . 158
12.2.1.4 Installing the ODD . . . . . . . . . . . . . . . . . . . . . . 159
12.2.1.5 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . 159
12.2.2 Removing an ODD . . . . . . . . . . . . . . . . . . . . . . . . 160
12.2.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 160
12.2.2.2 Removing an ODD . . . . . . . . . . . . . . . . . . . . . . 160

Fujitsu PRIMERGY TX1310 M3 Specifications

General

Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V6
System bus rate	8 GT/s
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
Number of processors installed	1
ECC	Yes
Internal memory	8 GB
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 10
HDD capacity	1000 GB
HDD interface	Serial ATA III
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	- TB
Number of HDDs installed	2
On-board graphics card model	Intel® HD Graphics 630
LAN controller	Intel® I219
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	-
USB 2.0 ports quantity	3
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Chassis type	Tower
Compatible operating systems	Microsoft Hyper-V Server 2012 R2 Microsoft Hyper-V Server 2016 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2016 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 2016 Essentials Microsoft Windows Server 2012 R2 Foundation Microsoft Windows Storage Server 2012 R2 Standard Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2012 Foundation SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7
Power supply	250 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	No
Operating temperature (T-T)	10 - 35 °C
Certification	CB, RoHS, WEEE, GS, CE, CSA us, ULc/us, FCC Class A, VCCI:V3 Class A + JIS 61000-3-2, KC, CCC, C-Tick (AS / NZS CISPR 22 Class A)
Sustainability certificates	EPEAT Gold

Weight and Dimensions

Depth	305 mm
Width	180 mm
Height	375 mm
Weight	14000 g
