Fujitsu PRIMERGY TX1310 M3 Upgrade And Maintenance Manual

Upgrade and Maintenance Manual TX1310 M3
Contents
12.2.2.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 161
12.2.3 Replacing an ODD . . . . . . . . . . . . . . . . . . . . . . . 161
12.2.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 161
12.2.3.2 Replacing an ODD . . . . . . . . . . . . . . . . . . . . . 161
12.2.3.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 162
12.3 Backup drive (RDX) . . . . . . . . . . . . . . . . . . . . . . 163
12.3.1 Installing a backup drive . . . . . . . . . . . . . . . . . . . . 163
12.3.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 163
12.3.1.2 Removing the dummy cover bay 2 . . . . . . . . . . . . . 164
12.3.1.3 Preparing the backup drive . . . . . . . . . . . . . . . . . 167
12.3.1.4 Installing the backup drive . . . . . . . . . . . . . . . . . . 168
12.3.1.5 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 169
12.3.2 Removing a backup drive . . . . . . . . . . . . . . . . . . . . 169
12.3.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 169
12.3.2.2 Removing a backup drive . . . . . . . . . . . . . . . . . . 170
12.3.2.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 170
12.3.3 Replacing a backup drive . . . . . . . . . . . . . . . . . . . . 171
12.3.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 171
12.3.3.2 Replacing a backup drive . . . . . . . . . . . . . . . . . . 171
12.3.3.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 172
13 Front panel and front USB . . . . . . . . . . . . . . . . . . 173
14 Serial connector . . . . . . . . . . . . . . . . . . . . . . . . 175
14.1 Installing the serial connector . . . . . . . . . . . . . . . . 175
14.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 175
14.1.2 Breaking off the metal cover . . . . . . . . . . . . . . . . . . 176
14.1.3 Installing the serial connector . . . . . . . . . . . . . . . . . . 176
14.1.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 177
14.2 Removing the serial connector . . . . . . . . . . . . . . . . 178
14.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 178
14.2.2 Removing the serial connector . . . . . . . . . . . . . . . . . 178
14.2.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 179
14.3 Replacing the serial connector . . . . . . . . . . . . . . . . 180
14.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 180
14.3.2 Removing the serial connector . . . . . . . . . . . . . . . . . 180
14.3.3 Installing the serial connector . . . . . . . . . . . . . . . . . . 180

Fujitsu PRIMERGY TX1310 M3 Specifications

General

Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V6
System bus rate	8 GT/s
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
Number of processors installed	1
ECC	Yes
Internal memory	8 GB
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 10
HDD capacity	1000 GB
HDD interface	Serial ATA III
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	- TB
Number of HDDs installed	2
On-board graphics card model	Intel® HD Graphics 630
LAN controller	Intel® I219
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	-
USB 2.0 ports quantity	3
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Chassis type	Tower
Compatible operating systems	Microsoft Hyper-V Server 2012 R2 Microsoft Hyper-V Server 2016 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2016 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 2016 Essentials Microsoft Windows Server 2012 R2 Foundation Microsoft Windows Storage Server 2012 R2 Standard Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2012 Foundation SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7
Power supply	250 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	No
Operating temperature (T-T)	10 - 35 °C
Certification	CB, RoHS, WEEE, GS, CE, CSA us, ULc/us, FCC Class A, VCCI:V3 Class A + JIS 61000-3-2, KC, CCC, C-Tick (AS / NZS CISPR 22 Class A)
Sustainability certificates	EPEAT Gold

Weight and Dimensions

Depth	305 mm
Width	180 mm
Height	375 mm
Weight	14000 g
