Fujitsu PRIMERGY TX1310 M3 Upgrade And Maintenance Manual

TX1310 M3 Upgrade and Maintenance Manual
Contents
14.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 180
15 System board and components . . . . . . . . . . . . . . . . 181
15.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 181
15.2 Replacing the CMOS battery . . . . . . . . . . . . . . . . . 182
15.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 182
15.2.2 Replacing the defective CMOS battery . . . . . . . . . . . . . 183
15.2.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 184
15.3 Trusted Platform Module (TPM) . . . . . . . . . . . . . . . . 185
15.3.1 Installing the TPM . . . . . . . . . . . . . . . . . . . . . . . . 186
15.3.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 186
15.3.1.2 Installing the TPM . . . . . . . . . . . . . . . . . . . . . . 186
15.3.1.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . 188
15.3.2 Removing the TPM . . . . . . . . . . . . . . . . . . . . . . . 189
15.3.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 189
15.3.2.2 Removing the TPM . . . . . . . . . . . . . . . . . . . . . . 191
15.3.2.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . 192
15.3.3 Replacing the TPM . . . . . . . . . . . . . . . . . . . . . . . 193
15.3.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 193
15.3.3.2 Removing the defective TPM . . . . . . . . . . . . . . . . 194
15.3.3.3 Installing the new TPM . . . . . . . . . . . . . . . . . . . . 194
15.3.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . 194
15.4 Replacing the system board . . . . . . . . . . . . . . . . . . 195
15.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 197
15.4.2 Removing the system board . . . . . . . . . . . . . . . . . . . 198
15.4.3 Installing the system board . . . . . . . . . . . . . . . . . . . 200
15.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 202
16 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
16.1 Overview cables . . . . . . . . . . . . . . . . . . . . . . . . 205
16.2 Cabling plans . . . . . . . . . . . . . . . . . . . . . . . . . . 206
16.3 Replacing cables . . . . . . . . . . . . . . . . . . . . . . . . 214
16.3.1 Replacing the system cable (accessible drives / top HDD cage) . .
214
16.3.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . 214
16.3.1.2 Removing the defective system cable . . . . . . . . . . . . 214

Fujitsu PRIMERGY TX1310 M3 Specifications

General

Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V6
System bus rate	8 GT/s
Motherboard chipset	Intel® C236
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
Number of processors installed	1
ECC	Yes
Internal memory	8 GB
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
HDD size	3.5 \
HDD speed	7200 RPM
RAID levels	0, 1, 10
HDD capacity	1000 GB
HDD interface	Serial ATA III
Optical drive type	DVD-RW
Total storage capacity	2000 GB
Maximum storage capacity	- TB
Number of HDDs installed	2
On-board graphics card model	Intel® HD Graphics 630
LAN controller	Intel® I219
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	-
USB 2.0 ports quantity	3
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Chassis type	Tower
Compatible operating systems	Microsoft Hyper-V Server 2012 R2 Microsoft Hyper-V Server 2016 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2016 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 2016 Essentials Microsoft Windows Server 2012 R2 Foundation Microsoft Windows Storage Server 2012 R2 Standard Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2012 Foundation SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7
Power supply	250 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	No
Operating temperature (T-T)	10 - 35 °C
Certification	CB, RoHS, WEEE, GS, CE, CSA us, ULc/us, FCC Class A, VCCI:V3 Class A + JIS 61000-3-2, KC, CCC, C-Tick (AS / NZS CISPR 22 Class A)
Sustainability certificates	EPEAT Gold

Weight and Dimensions

Depth	305 mm
Width	180 mm
Height	375 mm
Weight	14000 g
