5 Operation Preparing for measurements
5-20 Edition 4 (05/2014) DMS Go+
5.5 Preparing for measurements
You can use the DMS Go+ to measure wall thicknesses
or distances and to assess residual wall thicknesses in
a simple way. The measured value is displayed directly.
Depending on the task definition, you can apply one of
the following measuring methods:
Measurement of residual wall thickness up to the first
echo with dual-element probes, for example in the
event of corrosion.
Measurement of a multi-echo sequence with good
surfaces on both sides of the test object.
Wall thickness measurement through coating by
evaluating the multi-echo sequence (DUAL-MULTI).
Simultaneous measurement of wall thickness and
coating thickness with single echo (TopCOAT, only
with DMS Go+ TC).
Wall thickness and residual wall thickness measure-
ment with a simultaneous determination of the cur-
rent sound velocity (Auto-V, only with DMS Go+ TC).
Note
The functions TopCOAT and Auto-V are de-
scribed in chapter 7 of this manual.
To prepare for measurements, you have to:
Select a suitable probe.
Select the suitable measurement mode.
Calibrate the A-scan display.
Calibrate the instrument for the selected probe and
measurement mode.
Connect a suitable probe (see Section Connecting a
probe, page 3-9).
Power the instrument on (see Section Starting the
DMS Go+, page 3-11).
The further steps are described in detail in the following.
