5 Operation Saving the settings
5-18 Edition 4 (05/2014) DMS Go+
5.4 Saving the settings
You can save the current instrument settings to a file on
the SD memory card. The files for the DMS
Go+ have
the file extension DGO and are saved to the directory
DMSGO\DATASETS on the memory card.
The file name can consist of a maximum of
20
characters.
– In the function group PARAM, select the function
SAVE P-SET.
– Press one of the left or right arrow keys.
– Press the arrow keys to mark the first character for
the file name.
– Press the center key of the keypad to select the
marked character.
– Choose other characters in the same way.
– Press the function key 2 (function BKSP) in order to
delete the last character.
– Finally, press the function key 4 (function CONFIRM)
in order to save the file with the parameter data set
under the specified name.
