6 Data Recorder Documenting measurements
6-40 Edition 4 (05/2014) DMS Go+
6.8 Documenting measurements
Data export
You can export the measured values recorded and the
attachments to the measured values for documentation
purposes.
You have a choice between the following file formats:
● CSV
● PDF
● XML
● DAT
The export file is stored in the directory DMSGO on the
memory card.
Only data of the currently loaded file are ex-
ported.
– Load a Data Recorder file (see Section Loading a
file, page 6-14).
– In the function group DR, select the function EX-
PORT.
– Press one of the left or right arrow keys in order to
select the file type to be exported.
– Press the function key 2 (function EXPORT) in order
to start the export. The export file is stored on the
memory card.
You can read, copy, or delete files by insert-
ing the SD memory card into the SD card
reader of your PC or by connecting the
DMS
Go+ to a PC via a USB cable (see Sec-
tion USB interface, page 9-3).
