Important information on wall thickness measurement using the DMS Go+ 1 Introduction
DMS Go+ Edition 4 (05/2014) 1-9
Probes
Please note that only probes specified in chapter 2 of
this manual are accepted for the DMS Go+.
V-path correction
The following probes have only one transducer element
and therefore require no V-path correction:
All probes equipped with a transmitter and a receiver el-
ement require a V-path correction due to the inclined po-
sition of their transducer elements (with wall thickness-
es < 60 mm in steel).
The V-path correction is stored in the DMS Go+ for the
following probes:
● K 1 SC ● K-PEN ● G5 KB
● G 2 N ● CLF 5 ● CLF 4
● CA 215 ● CA 214 ● CA 211
● CA 211 A ● A DFRP ● A2 DFR
● A2 DFR ● A2 10 M ● 5 M 5 DFR
● Alpha2 D ● CA 211A ● DA 301
● DA 303 ● DA 312 ● DA 312 B1
● DA 501 EN ● DA 503 EN ● DA 507
● DA 512 ● D 590 ● FH 2 E
● HT 400 A ● KBA 525 ● KBA 560
● OSS 10 ● TC 560 ● D 790
