Thickness profiles with the B-scan 5 Operation
DMS Go+ Edition 4 (05/2014) 5-43
Switching the B-scan display on
You can switch the B-scan display on any time.
The display of the thickness profile starts automatically
at the first successful coupling after switching the B-
scan display on.
Simultaneously with the B-scan display, the DMS Go+
determines the minimum reading detected during the
measurements. At the end of the selected display time,
this value is displayed above the B-scan, and you can
save the reading by pressing the function key
2 (func-
tion SEND).
Note
The processes of saving readings and docu-
menting measurement results are described
in detail in chapter 6.
– In the function group MEASURE, select the function
MODE.
– Choose the option B-SCAN in order to switch the B-
scan display on.
Setting the display time
The display time (in seconds) defines the period of time
during which the thickness profile should be recorded.
At the end of this time (maximum 30 seconds), the in
-
strument stops the measurements.
The scaling of the X-axis in the B-scan corresponds to
the selected display time.
– In the function group MEASURE, select the function
TIME.
– Set the required display time.
