Table 4-2. ECR NIC LED Descriptions
Product Configuration
NIC1
NIC2
ECR-4G + WiFi
Cellular
WiFi
ECR-4G Only
Cellular
Off
ECR-3G + WiFi
Cellular
WiFi
ECR-3G Only
Cellular
Off
ECR-WiFi only
Off
WiFi
ECR-900 + WiFi
WiFi
900 ISM (NxRadio)
ECR-900 Only
Off
900 ISM (NxRadio)
ECR-LN + WiFi
WiFi
Lic. Narrowband (LnRadio)
ECR-LN Only
Off
Lic. Narrowband (LnRadio)
Table 4-3. Cell Interface LED Descriptions
LED - NIC1
LED State
Description
Cell Interface
Off
Solid green
No cellular connection
Cell connection
Table 4-4. WiFi Interface LED Descriptions
LED - NIC1
LED State
Description
WiFi Interface
Off
Interface disabled
Access Point Mode
Solid Green
Solid Red
Operating as AP and at least one
client connection
Operating as an AP and no client
connection
Station Mode
Off
Solid Green
No connection
Wi-Fi connection established.
Table 4-5. NxRadio Interface LED Descriptions
LED - NIC2
State
Description
NxRadio Interface
Off
Interface disabled
Access Point Mode
Blink Red
Solid Red
Solid Green
NIC Initialization
No Remotes connected
Linked with at least 1 Remote
Remote Mode
Blink Red
Solid Green
NIC Initialization / Not linked to an Access
Point
Linked with Access Point
