384 MDS Orbit MCR/ECR Technical Manual MDS 05-6632A01, Rev. F
Table 4-9.Orbit MCR-900 Power Consumption:
Power Consumption (nominal, Output Power = 1W, 25C)
Mode
Power
13.8V
AP (Idle)
4.0W
293mA
AP (50% Duty)
5.3W
382mA
Remote (Associated, Idle)
3.2W
235mA
Remote (Associated, 50% Duty)
5.0W
365mA
Table 4-10.Orbit MCR-LN Power Consumption:
Power Consumption (nominal, Output Power = 1W, 25C)
Mode
Power
13.8V
AP (Idle)
12.6W
910mA
AP (50% Duty)
13.1W
950mA
Remote (Associated, Idle)
4.8W
350mA
Remote (Associated, 50% Duty)
10.8W
780mA
Ethernet Port(s)
RJ-45 10/100 Mbps Auto-MDIX
Serial Port(s)
RJ-45, supporting RS-232/RS-485
LAN Protocols
802.3 (Ethernet) 802.1D (Spanning Tree) TCP/IP, DHCP, ICMP, IGMP, FTP, TFTP,
SFTP, UDP, SNMP, VPN, VLAN
Networking
DHCP, Port Forwarding, NAT, VLAN, SNMP
Configuration
Serial console, SSH, HTTP/HTTPS, Configuration files
Security
Encryption, Password access, Radius, Firewall, SCEP, VPN
Physical
Size
8.0” long (20.32 cm), 4.8” wide (12.192 cm), 1.75” High (4.445 cm)
Housing
Die-cast Aluminum
Weight
2 lbs. (without mounting hardware)
Environmental
Operating Temperature Range
-40°C to +70°C
