1-4
If you have chosen 9600 bps as the download baudrate, you need not modify the HyperTerminal’s
baudrate, and therefore you can skip Step 4 and 5 below and proceed to Step 6 directly. In this case,
the system will not display the above information.
Following are configurations on PC. Take the HyperTerminal in Windows 2000/Windows XP as an
example.
On the Windows 2003 Server operating system, you need to add the HyperTerminal program first, and
then log in to and manage the device as described in this document. On the Windows 2008 Server,
Windows 7, Windows Vista, or some other operating system, you need to obtain a third party terminal
control program first, and follow the user guide or online help of that program to log in to the device.
Step 4: Choose [File/Properties] in HyperTerminal, click <Configure> in the pop-up dialog box, and then
select the baudrate of 115200 bps in the Console port configuration dialog box that appears, as shown
in
Figure 1-1, Figure 1-2.
Figure 1-1 Properties dialog box
