Hexagon RDS - Information of the Package

RDS Toolbox Vault – secured area
H000002007-RDS User Manual │Version 5.0.0 (2018-09-17) │124
I.3.2 INFORMATION OF THE PACKAGE
The identification number and the location of the file can be retrieved from the vault:
• Select the package
Or
• Do a right click on the package
• use the Information action button
A Popup appears above the package line:
Depending on the type of package and its Local status, the following information can be found:
Package information (all packages)
Package name
Identification number of the package
File size
Locate on disk
When clicking on this line, a link to the folder becomes available
: opens the browser on the Vault folder and pre-selects the package
file
Calibration report (Calibration packages)
Opens the complete Calibration report text file
spat, min, ….
Mean, min and max values for the spatial errors.
rep, min, ….
Mean, min and max values for the repeatability errors.
stat, min, ….
Mean, min and max values for the static errors.
