I.2 TYPES OF PACKAGES
A package (extension *.pck) is a group of files that can be backup, stored, uploaded, downloaded, restored.
It can contain Alignment data, armspecs, … for any maintenance purpose.
The Memory of the arm is composed by 2 blocks:
• A UserSpecs block (default used data)
• A Backup specs block (Last Service Centre Alignment data)
In case the UserSpecs block is damaged or not readable, RDS will try to use the Backup
specs (and will prompt a warning).
In case of wrong operation on the UserSpecs, the Backup Specs can be restored into the
UserSpecs block and restore the memory as it was after the last Alignment by the Service
Centre.
If the complete memory is damaged, it is possible to download the package and restore it.
Type
Description
Cal
Calibration
RDS Data Collector raw data
+ Armspecs
Ce
Certification
RDS Data Collector Raw data
+ Armspecs
Op
Optimization
RDS Data Collector Raw data
+ Armspecs
Bk
Backup
Backup specs block of the arm
Pr
Tune-up / Profile
Fa
Factory specs
Original Backup + User specs blocks
Di
Diagnosis
RDS Toolbox axes signal
Tc
Temp compensation
Sm
SMART Data set
All SMART indicators for one period.
: all users / : Technicians only
Some other types of packages can be used only in Technician profile. Please refer to the
RDS Technician manual.
