RDS Toolbox Maintenance
H000002007-RDS User Manual │Version 5.0.0 (2018-09-17) │170
K.1.3 HOW TO … PROGRAM A PROBE
1. Connect the arm to the computer through USB
2. Plug the probe through the TKJ connector
3. Run RDS Toolbox and select “Program a probe”.
4. In the list of probes, select the appropriate one
5. Click “Program a probe” button.
6. Confirm the following question
7. RDS displays the information message:
8. Once the message is validated, the probe is added to the list of probes in the memory of the arm, and
the probe Alignment is requested.
The probe programming affects the memory of the probe itself, not the memory of the arm:
if the probe was already in the memory of the arm, delete it to be recreated with the new
programming.
