C.1.3 STATUS DETAILS
To get details about one component, click on the wanted icon.
System Status
Item
Status
Action
RDS Service
Running / Stopped
Stop ( ) /
Start
Shows the activity of the component and
gives a quick way to restart it.
RDS Toolbox
Running / Stopped
Stop / Start
RDS Agent
Stop
Minimise window at
start-up
Active / Inactive
(default=inactive)
Activate
Configuration of the RDS Agent window
display.
(default = inactive)
Always on
foreground
Active / Inactive
(default=inactive)
Activate
Opacity
Percentage of
opacity
(default = 100%)
Set the value
: at least advanced user.
Connection status
Item
Type
Shows the type of connection to the machine
USB / WLAN /
Ethernet
Status
Shows the connectivity status
Connected /
Connecting …
Control Panel
Gives access to RDS Control Panel for the configuration
Machine status
Item
Status
S/N
Shows the serial number of the connected instrument, when available
Arm Type
Shows the type of machine (MG, RA7, RA8…)
Extension Pack
Shows the type of Control / Feature Pack (CP1, FP2…)
Temperature
Humidity
Pressure
Gives the current temperature (°C)
• ambient temperature measured by the instrument (onboard sensor)
• external temperature measured by an external sensor (WTS, Bluetooth
sensor…)
Ext. temperature
Gives the current temperature measured by an external sensor (WTS, Bluetooth
sensor…)
Control Panel
Gives access to RDS Control Panel for the configuration
