J. SMART
J.1 PRESENTATION
RDS Toolbox contains an interface for a “Self-Monitoring, Analysis and Reporting Technology” on the arm
(SMART): it is checking the global status of the arm, connection and its components through several
indicators on the system.
RDS Toolbox collects all the SMART information every time an arm is connected to the computer. Thus, it
is possible to have a look on the detailed status of all the previously connected arms (including the currently
connected one) and components. This includes several indicators and possible alerts if some indicators
overpass specified limits.
Several indicators get information from sensors on the arm; even when the arm is not connected, the
sensors collect data. The data are synchronized with HEXAGON SERVER through the computer (SMART
Data set packages) as soon as the arm is connected to the computer.
With this tool, it is possible to survey the arm and prevent from potential damages.
HEXAGON®
SERVER
Database
Distant arms through
SMART Data set packages
View Alerts
View statistics
Analyse indicators
Local mode Database mode
Local SMART memory:
Local arms
(connected and off-line)
Collects Arms + Computer+ connection indicators
Analyse the indicators
Create and display alerts
Arm 2
Arm 1
. . . .
HEXAGON®
SERVER
sorting
SMART Data set
