D.2.6 WIRED ETHERNET CONNECTION (ARM / TRACKER)
Please follow the instruction below to connect RDS to the arm (Absolute Arm or Cimcore CA7 Arm with
FP3+ / CP3) or the tracker through wired Ethernet.
Machine setup
1. Power on the machine.
2. Ensure that the Ethernet cable is correctly connected from the machine to the computer
RDS setup
3. Enter RDS Control Panel
4. Select Connection tab
5. Select the type of machine and Wired Ethernet link type
Connection
