9.4 Message Reference
152
Queries the contents of the set-value for withstand-voltage tests
Syntax
(Query)
:CONFigure:WITHstand?
Queries the contents of the set-value for withstand-voltage tests.
(Response)
<Test-voltage>,<Current upper-limit value>,
<Current lower-limit value>,<Test time>,<Test frequency>,
<Ramp-up time>,<Ramp-down time>,
<initial voltage for ramp-up>,<contact check upper-limit voltage>,
<contact check lower-limit voltage>
Test-voltage..................................0.20 to 5.00 (NR2, unit: kV)
Current upper-limit value..............0.1 to 20.0 (NR2, unit: mA)
Current lower-limit value ..............0.1 to 19.9 (NR2, unit: mA)
0: OFF
Test time.......................................0.3 to 999 (NR1/NR2, unit: s)
0: OFF
Test frequency..............................AC50 / AC60 (unit: Hz)
Ramp-up time ..............................0.1 to 99.9 (NR2, unit: s)
0: OFF
Ramp-down time.......................... 0.1 to 99.9 (NR2, unit: s)
0: OFF
initial voltage for ramp-up............. 0.0 to 1.0 (NR2)
contact check upper-limit voltage. 0.20 to 5.00 (NR2, unit: kV)
0: OFF
contact check lower-limit voltage .0.20 to 5.00 (NR2, unit: kV)
0: OFF
Example
(Query)
:CONFigure:WITHstand?
(Response)
1.50,5.0,0.1,30.0,AC50,10.0,5.0,0.2,2.00,1.00
The settings for withstand test are as follows.
Test-voltage.................................... 1.5 kV
Current upper-limit value................ 5.0 mA
Current lowper-limit value............... 0.1 mA
Test time set value ......................... 30.0 s
Test frequency................................ 50 Hz AC
Ramp-up time................................. 10.0 s
Ramp-down time ............................ 5.0 s
initial voltage for ramp-up............... 0.2 kV
contact check upper-limit voltage... 2.0 kV
contact check lower-limit voltage.... 1.0 kV
