9.4 Message Reference
154
Sets and Queries the test-voltage value for withstand-voltage tests
Syntax
(Command)
:CONFigure:WITHstand:VOLTage <0.20 to 5.00 (NRf)>
Sets the test-voltage value (unit: kV) for withstand-voltage tests in the
READY state.
(Query)
:CONFigure:WITHstand:VOLTage?
Queries the test-voltage value (unit: kV) for withstand-voltage tests.
(Response)
<0.20 to 5.00 (NR2)>
Example
(Command)
:CONFigure:WITHstand:VOLTage 1.00
Sets the test-voltage value for withstand-voltage tests at 1.00 kV.
(Query)
:CONFigure:WITHstand:VOLTage?
(Response)
1.00
The test-voltage value is 1.00 KV.
Error
• The execution of this command in a state other than the READY state or "test
setting state" causes an execution error.
However, in the optional function mode, when the interface command “START”
is valid, the voltage during testing can be changed. If the interface command
“START” is invalid, the execution of this command causes an execution error.
Note
• To change the voltage during test, set "START" for the interface command to
"Start command valid", which is an optional function setting.
• In the optional function mode, when the output voltage is restricted, a value
higher than the restricted value cannot be set.
Sets and Queries the upper-limit test value for withstand-voltage tests
Syntax
(Command)
:CONFigure:WITHstand:CUPPer <0.1 to 20.0 (NRf)>
Sets the upper-limit test value (unit: mA) for withstand-voltage tests,
in the READY state.
(Query)
:CONFigure:WITHstand:CUPPer?
Queries the upper-limit test value (unit: mA) for withstand-voltage
tests.
<0.1 to 20.0 (NR2)>
Example
(Command)
:CONFigure:WITHstand:CUPPer 5.0
Sets the upper-limit test value for withstand-voltage tests to 5.0 mA.
(Query)
:CONFigure:WITHstand:CUPPer?
(Response)
5.0
The upper-limit test value is 5.0 mA.
Error
• The execution of this command in a state other than the READY state or "test
setting state" causes an execution error.
• When the lower limit of the withstand-voltage test is set to ON, an execution
error will occur when "upper limit test value ≤ lower limit test value" is set.
