9.4 Message Reference
162
Queries the withstand-voltage test result
Syntax
(Query)
:MEASure:RESult:WITHstand?
Queries the results of the preceding test. Returns the determination
and valid values at termination of the preceding test. The test results
are updated upon termination of a new test.
(Response)
<Withstand-voltage test measured voltage value>,
<Measured current value>,<Test time elapsed>,
<Determination>,<Types of timers>
Withstand-voltage test measured voltage value
........................................(NR2, unit: kV)
Measured current value ..(NR2, unit: mA)
Test time elapsed............(NR2, unit: s)
Determination..................PASS/ UFAIL/ LFAIL/ ULFAIL/ OFF
PASS : PASS
UFAIL : UPPER-FAIL
LFAIL : LOWER-FAIL
ULFAIL : UPPER-LOWER-FAIL
OFF :
Others
Types of timers................0/ 1/ 2 (NR1)
0: test time
1: ramp-up time
2: ramp-down time
Example
(Query)
:MEASure:RESult:WITHstand?
(Response)
1.00,2.00,30.0,PASS,0
Withstand-voltage test result
Measured voltage value: 1.00 kV; Measured current value: 2.00 mA;
Test time elapsed: 30.0 s; Determination: PASS; Types of timers: test time
Error
The execution of this command in a state other than the READY state or "test set-
ting state" causes an execution error.
Note
• When the instrument indicates “- - -“ for a current value, the command’s current
measurement value will return 99.99 (10 mA-range) / 99.9 (20 mA-range).
• Contact error type will not return.
Queries the measured voltage value for withstand-voltage tests
Syntax
(Query)
:MEASure:WITHstand:VOLTage?
Queries the measured voltage value (unit: kV) for withstand-voltage
tests.
(Response)
<Measured voltage value for withstand-voltage tests (NR2)>
Example
(Query)
:MEASure:WITHstand:VOLTage?
(Response)
1.00
The measured voltage value is 1.00 kV.
Error
The execution of this command in a state other than the TEST state causes an
execution error.
