9.4 Message Reference
167
99
Sets and Queries the lower-limit test value for insulation-resistance tests
Syntax
(Command)
:CONFigure:INSulation:RLOWer <0.20 to 2000 (NRf)>
Sets the lower-limit test value (unit: MΩ) for insulation-resistance
tests, in the READY state.
(Query)
:CONFigure:INSulation:RLOWer?
Queries the lower-limit test value (unit: MΩ) for insulation-resistance
tests.
(Response)
<0.20 to 2000 (NR1/NR2)>
Example
(Command)
:CONFigure:INSulation:RLOWer 10.0
Sets the lower-limit test value for the insulation-resistance tests to 10.0 MΩ.
(Query)
:CONFigure:INSulation:RLOWer?
(Response)
10.0
The lower-limit test value is 10.0 MΩ.
Error
• The execution of this command in a state other than the READY state or "test
setting state" causes an execution error.
• When the upper limit of the insulation-resistance test is set to ON, an execution
error will occur when “upper limit test value < lower limit test value” is set.
An execution error will occur when a value exceeding the resistance measure-
ment range is set.
When the test-voltage is 1000 V, values below 1.00 MΩ are outside the resis-
tance measurement range.
Refer to "4.1.2 Setting the Upper (Lower) Limit Value" (p. 51) for resistance
measurement ranges.
Sets and Queries the test time for insulation-resistance tests
Syntax
(Command)
:CONFigure:INSulation:TIMer <0.3 to 999 (NRf)>
Sets the test time (unit: s) for insulation-resistance tests, in the
READY state.
(Query)
:CONFigure:INSulation:TIMer?
Queries the test time (unit: s) for insulation-resistance tests.
(Response)
<0.3 to 999 (NR1/NR2)>
Example
(Command)
:CONFigure:INSulation:TIMer 10.0
Sets the test time for the insulation-resistance tests to 10.0 s.
(Query)
:CONFigure:INSulation:TIMer?
(Response)
10.0
The test time is set to 10.0 s.
Error
The execution of this command in a state other than the READY state or "test set-
ting state" causes an execution error.
