9.4 Message Reference
173
99
Queries the contents of the set-value memory for insulation-resistance tests
Syntax
(Query)
:MEMory:INSulation:FILE? <1 to 8 (NR1)>
Queries the contents of the set-value memory for the insulation-resis-
tance test number specified.
(Response)
<Test-voltage value>,<Upper-limit value>,<Lower-limit value>,
<Test time setting value>,<Delay time setting value>
<contact check upper-limit voltage>,
<contact check lower-limit voltage>
Test-voltage value................ 500, 1000 (NR1, unit: V)
Upper-limit value.................. 0, 0.20 to 2000 (NR1/NR2, unit: MΩ)
0: OFF
Lower-limit value.................. 0.20 to 2000 (NR1/NR2, unit: MΩ)
Test time setting value ......... 0, 0.3 to 999 (NR1/NR2, unit: s)
0: OFF
Delay time setting value....... 0, 0.1 to 99.9 (NR2, unit: s)
0: OFF
contact check upper-limit voltage. 600, 1200 (NR1, unit: V)
0: OFF
contact check lower-limit voltage . 500, 1000 (NR1, unit: V)
0: OFF
Example
(Query)
:MEMory:INSulation:FILE? 1
Queries the contents of set-value memory file 1 for insulation-resistance tests.
(Response)
3,1000,0,100,5.0,1.0,1200,1000
Insulation-resistance test; Test voltage: 1000 V;
Upper-limit value: OFF; Lower-limit value: 100 M
Ω; Test time: 5.0 s;
Delay time: 1.0 s; contact check upper-limit voltage: 1200 V; contact check
lower-limit voltage: 1000 V
Error
• An execution error occurs when file numbers other than 1 to 8 are specified.
• Execution error appears when a mistake occurs in the combination of the test
voltage and upper-limit voltage for Contact Check.
Test voltage: 500 V → contact check upper-limit voltage: 600 V, contact check
lower-limit voltage: 500 V
Test voltage: 1000V → contact check upper-limit voltage: 1200 V, contact check
lower-limit voltage: 1000 V
