9.4 Message Reference
175
99
Sets the optional functions 1
Syntax
(Command)
:SYStem:OPTion:P1 <Pass hold function>,
<Fail hold function>,<STOP Hold function>,
<Momentary output function>,<Double action function>,
<Fail mode function>,
<Interface command "START" function>,<Inter-lock function>,
<Output-voltage restricting value>
Sets the contents on Page 1 of the Optional Function Setting Screen.
(Data)
<Pass hold function>,<Fail hold function>,<STOP Hold function>,
<Momentary output function>,<Double action function>,
<Fail mode function>,<Interface command "START" function>,
<Inter-lock function>,<Output-voltage restricting value>
Pass hold function ............... 0/1 (NR1)
0: Not held
1: Held
Fail hold function..................0/1 (NR1)
0: Not held
1: Held
STOP Hold function ............. 0/1 (NR1)
0: Not held
1: Held
Momentary output function ..0/1 (NR1)
0: Not set
1: Set
Double action function ......... 0/1 (NR1)
0: Not set
1: Set
Fail mode function ............... 0/1 (NR1)
0: Not set
1: Set
Interface command "START" function
.............. 0/1/2/3 (NR1)
0: Start command invalid, changing the voltage supplied using
keys not possible
1: Start command valid, changing the voltage supplied using keys
not possible
2: Start command invalid, changing the voltage supplied using
keys possible
3: Start command valid, changing the voltage supplied using keys
possible
Inter-lock function ................ 0/1 (NR1)
0: Not set
1: Set
Withstand-voltage test
Output-voltage restricting value ..... 0.2 to 5.0 (NR2, unit: kV)
Example
(Command)
:SYStem:OPTion:P1 1,1,0,0,0,0,1,0,3.2
Set the contents on Page 1 of the Optional Function Setting as follows.
Pass hold function: Held, Fail hold function: Held,
STOP Hold function: Not held,
Momentary output function: Not set, Double action function: Not set,
Fail mode function: Not set, Interface command "START" function: Start com-
mand valid, changing the voltage supplied using keys not possible,
Inter-lock function: Not set,
Withstand-voltage test Output-voltage restricting value: 3.2 kV
Error
• The execution of this command in a state other than the READY state causes
an execution error.
• Execution error appears when value other than specified is set.
