IOLINK Block
Main Tab
R301.1 Experion C300 Controller User's Guide 123
11/06 Honeywell
Plain Text Parameter Name
User
Configurable
Notes
Priority IOMs
NUMPRIORITYIOM
No
Shows the number of
IOMs configured as
Priority IOMs on the
IOLINK.
I/O Link Cable Color
IOLINKCOLOR
No
Shows the link cable
color assigned to the
IOLink number.
I/O Link Number
LINKNUM
No
Shows the link number
within the I/O Link
Interface.
I/O Link State
STATE
The state of the IOLink,
(NOTLOADED,
ONLINE)
I/O Link Soft Fail Errors
(See Troubleshooting
section for more information.)
Duplicate IOL
Address
DUPIOLADDR
No
Indicates if a duplicate
IOLink address has
been detected.
IOL Channel A
Failure
IOLCHNFAILA
No
Indicates if Channel A
of the IOLink has failed.
IOL Channel B
Failure
IOLCHNFAILB
No
Indicates if Channel B
of the IOLink has failed.
IOL Maximum Errors
Exceeded
IOLMAXERR
No
Shows the I/O link has
exceeded the maximum
error limit.
Not Active Supervisor
NOTACTSUPV
No
Indicates that the IOL
interface daughter card
could not transition into
the active supervisor
role.
IOLIM Daughter Card
Soft Failure
IOLDAUGHSF
No
Shows whether or not a
soft failure exists in the
associated IOLINK's
daughter card.
