Communication and system time startup fault scenarios
Secondary C300 Controller with no Memory Retention
R301.1 Experion C300 Controller User's Guide 247
11/06 Honeywell
Controller Faceplate Problem
C300 Block
Time Source
Station Alarm Resolve
FTE
LEDs
Off
Display
COMM
CB icon
Red
Status
LED
Blinking
Orange
FTE
LEDs
Blinking
Green
Display
BKUP
CB icon
Grey
Communication on FTE
network.
• No communication via CDA
• Unable to establish
connection to system time
source
None None Note 2
Status
LED
Blinking
Orange
FTE
LEDs
Blinking
Green
Display
BKUP
CB icon
Red ->
Blue
Communication on FTE
network
• Communication via CDA
• Unable to establish
connection to system time
source
CDA C300 Not
Synchronized
Note 3
Status
LED
Blinking
Orange
FTE
LEDs
Blinking
Green
Display
BKUP
CB icon
Grey
Communication on FTE
network
• No communication via CDA
• Established connection to
system time source
SNTP
• CDA comm
Lost
Connection
• C300 Not
Synchronized
Note 4
Status
LED
Blinking
Orange
FTE
LEDs
Blinking
Green
None. Normal operation for
redundant secondary
controller with no battery
backup following a power
cycle.
SNTP C300 Not
Synchronized
None.
