Identify C300 Controller components
I/O modules supported by the C300 Controller
14 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Series C
Component
Description Model Number
firewall module.
STP CAT5 Cable with RJ 45 connectors
for FTE connections.
2 m (6.5 ft)
(Y) = Yellow coded boots
(G) = Green coded boots
51305482-102 (Y)
513054820202 (G)
5 m (16 ft)
51305482-105 (Y)
513054820205 (G)
10 m (33 ft)
51305482-110 (Y)
513054820210 (G)
FTE Cable
20 m (65.5 ft)
51305482-120 (Y)
51305482-220 (G)
Redundancy
Cable
STP CAT5 Cable with RJ 45 connectors
joining primary and secondary controllers.
51305482-xxx
IOLink Cable
Multidrop cable assemblies to connect the
I/O modules of a controller IOLink.
xxxxxxxx-xxx
Battery Cable
Multidrop twisted pair cable to connect
battery power to controllers.
xxxxxxxx-xxx
IOTA Channel
Supports
Aluminum channels that provide a
mounting medium for the IOTA Carrier.
CC-MCHN01
IOTA Carrier
Assembly for mounting Series C Hardware
IOTAs. Carriers contain power and
grounding busbars are mounted onto
IOTA channel supports.
CC-MCAR01
Power Supply,
Non-redundant
no Battery Back
Up
24 Vdc, 20 Amp. power supply. Provides
non-redundant power to Carrier busbars
and Series C IOTAs.
CC-PWRN01
Power Supply
Redundant, no
Battery Back Up
24 Vdc, 20 Amp. fully redundant power
supply. Provides redundant power to
Carrier busbars and Series C IOTAs.
CC-PWRR01
Power Supply,
Redundant with
Battery Back Up
24 Vdc, 20 Amp. fully redundant power
supply with battery back up. Provides
redundant power to Carrier busbars and
CC-PWRB01
