9 Replacing components
162
HSD S.p.A. © - h0108k01a.fm120718
8
Tighten two 5x16 screws in the two
oval-shaped holes (“A”) near the
piston screw dowel, but leave a
little bit of play.
Remove the eight 5x10 screws
(“B”) around the screw dowel.
Move the two screws in the oval
holes radially outwards (direction
“C”), then tighten them so they are
blocked in this position.
Op. Description Picture
