JLG 4394RT - Axial HI 45 Pump - Cross Section View

SECTION 4 - HYDRAULICS
4-24 – JLG Lift – 3121642
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1. Electric Displacement Control
2. Swashplate Feedback Pin
3. Piston
4. Slipper
5. Shaft Seal
6. Shaft
7. Front Bearing
8. Swashplate Bearing
9. Swashplate
10. Cylinder Block
11. Charge Pump
12. Rear Bearing
13. Valve Plate
14. Servo Piston
Figure 4-25. Axial HI 45 Pump - Cross Section View
