Relays
REMOVAL:
1. Disable machine operation.
2. Disconnect and label the wires and harnesses attached
to the weather proof relay (1), solenoid relay (2) and
glow plug harness (7).
3. Remove the relays from the mounting bracket (6) by
removing the bolts (3), locknuts (4) and washers (5).
4. The relay mounting bracket can be removed from the
muffler mounting bracket (10) by removing the two
bolts, nuts and washers (not shown).
INSTALLATION:
1. Follow Removal Steps in reverse.
1
2
3, 4, 5
6
7, 8, 9
10
1. Weather Proof Relay
2. Solenoid Relay
3. Bolt, NO10-24 x 0.75"
4. Locknut
5. Washer
6. Relay Mounting Bracket
7. Glow Plug Harness
8. Bolt, NO8-32 x 0.625"
9. Locknut
10. Muffler Mounting Bracket
Figure 3-65. Relays (Deutz Engine)
