JLG 4394RT - Machine Configuration Programming Information

SECTION 5 - JLG CONTROL SYSTEM
3121642 – JLG Lift – 5-19
NOTE: When configuring an RT, the Machine Configuration must
be completed before any Personality settings can be
changed. Changing the Personality settings first and then
changing the Model of the Machine Configuration will
cause the Personality settings to return to default values.
Table 5-3. Machine Configuration Programming Information
Configuration Digit Setting Description Default Number
1
(MODEL)
0
1
2
3
33RT 2WD
33RT 4WD
43RT 2WD
43RT 4WD
1
2
(ENGINE)
0
1
2
3
4
5
6
FORD EFI D/F
DEUTZ F3
FORD D/F (T2)
DEUTZ F3 (T2)
DEUTZ ECM
DUAL FUEL ECM - GM/PSI Engine
DEUTZ T4F ECM
4
3
(MARKET)
0
1
2
3
4
ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
0
4
(TILT CUTOUT)
0
1
NO - Tilt Cutout is not active
Yes - Tilt Cutout is active
(Screen only visible to CE Market)
1
5
(GLOW PLUGS)
0
1
2
3
4
5
6
7
NO GLOW PLUGS
5 SEC GLOW
10 SEC GLOW
20 SEC GLOW
30 SEC GLOW
40 SEC GLOW
50 SEC GLOW
60 SEC GLOW
5
6
(LEVELING JACKS)
0
1
No - Leveling Jacks not installed on vehicle.
YES – Leveling Jacks are installed on vehicle.
0
7
(POWER DECK)
0
1
2
NONE – Power Deck Extensions not installed on vehicle.
FRONT – Power Deck Extension is installed on the Front of the vehicle.
DUAL – Power Deck Extensions are installed on the Front and Rear of the vehi-
cle.
0
8
(GENERATOR)
0
1
2
NOT INSTALLED – Generator is not installed on the vehicle.
60HZ – Generator is installed and engine speed set for 2000RPM when
enabled.
50HZ – Generator is installed and engine speed set for 1700RPM when
enabled.
0
9
(FUNCTION CUT-
OUT)
0
1
2
NOT INSTALLED – Vehicle is not equipped with a Function Cutout device.
DRV & LIFT UP – Vehicle is equipped with a Function Cutout device. Drive and
Lift Up will be prevented when active.
ALL FUNCTIONS – Vehicle is equipped with a Function Cutout device. All
Functions will be prevented when active.
0
