SECTION 5 - JLG CONTROL SYSTEM
5-20 – JLG Lift– 3121642
10
(LOAD)
0
1
2
NOT INSTALLED – Load Sensing System (LSS) is not fitted to the vehicle.
CUTOUT PLT – Load Sensing System (LSS) is fitted, and Platform Controls are
prevented in the event of an Overload. Ground Controls remain functional.
This is the default setting for CE machines.
CU TOU T AL L – Load Sen sin g S yste m (L SS) is fit te d. Pl atfo rm a nd Grou nd Con -
trols are prevented in the event of an Overload.
NOTE: Certain market selections will alter default setting.
0
11
(GROUND ALARM)
0
1
2
NOT INSTALLED – Vehicle alarm will function for Overload (if LOAD enabled).
DESCENT – Vehicle alarm will function for Overload (if LOAD enabled) and
du rin g L ift D own motio n.
MOTION – Vehicle alarm will function for Overload (if LOAD enabled), during
Drive motion, and during Lift motion.
NOTE: Certain market selections will alter default setting.
2
12
(ENGINE SHUT-
DOWN)
0
1
NO - The engine will not be automatically shutdown.
SHUTDOWN - The engine will automatically shutdown in the event of high
engine coolant temperature, low oil pressure, or a temperature sensor or oil
pressure sensor fault.
1
4150390 M
Table 5-3. Machine Configuration Programming Information
Configuration Digit Setting Description Default Number
Table 5-4. Machine Tilt Configuration
Model Market LImits
33RT 2WD,
33RT 4WD
ANSI USA
Lift Up and Drive prevented when Elevated and Tilted beyond the following limits:
Front to Back: ±5° to Full Height
Side t o S ide: ±5° t o 2 6 Fe et ; ± 4° to 30 Fe et ; ± 3° to Fu ll He ig ht
ANSI EXPORT Same as ANSI USA
CSA
Lift Up and Drive prevented when Elevated and Tilted beyond the following limits:
Front to Back: ±3° to Full Height
Side t o S ide: ±3° t o F ul l H ei gh t
CE
Tilt Lamp energized when Tilted beyond the following limits:
Front to Back: ±5° to Full Height
Side t o S ide: ±3° t o F ul l H ei gh t
AUSTRALIA Same as ANSI USA
43RT 2WD
43RT 4WD
ANSI USA
Lift Up and Drive prevented when Elevated and Tilted beyond the following limits:
Front to Back: ±5° to Full Height
Side to Side: ±5° to 30 Feet; ±4° to 36 Feet; ±3° to Full Height
ANSI EXPORT Same as ANSI USA
CSA
Lift Up and Drive prevented when Elevated and Tilted beyond the following limits:
Front to Back: ±3° to Full Height
Side t o S ide: ±3° t o F ul l H ei gh t
CE
Tilt Lamp energized when Tilted beyond the following limits:
Front to Back: ±5° to Full Height
Side t o S ide: ±3° t o F ul l H ei gh t
AUSTRALIA Same as ANSI USA
4150390 M
NOTE: Vehicle Tilt Configuration based on Model and Market Settings
