SECTION 5 - JLG CONTROL SYSTEM
5-4 – JLG Lift– 3121642
Adjusting Parameters Using the Hand Held
Analyzer
Once you have gained access to level 1, and a personality item
is selected, press the UP or DOWN arrow keys to adjust its
value, for example:
PERSONALITIES:
DRIVE ACCEL 3.0s
There will be a minimum and maximum for the value to
ensure efficient operation. The value will not increase if the UP
arrow is pressed when at the maximum value nor will the
value decrease if the DOWN arrow is pressed and the value is
at the minimum value for any particular personality. If the
value does not change when pressing the up and down
arrows, check the access level to ensure you are at access level
1.
Machine Setup
When a machine digit item is selected, press the UP or DOWN
arrow keys to adjust its value, for example:
FAILURE TO MAKE THE PROPER SETTINGS FOR THE PARTICULAR MACHINE
CAN RESULT IN IMPROPER OPERATION.
GROUND ALARM:
1=DESCENT
The effect of the machine digit value is displayed along with
its value. The above display would be selected if the machine
was equipped with a ground alarm and you wanted it to
sound when driving. There are certain settings allowed to
install optional features or select the machine model.
When selecting the machine model to match the size of the
machine, the personality settings will return to default set-
tings.
PERSONALITIES:
DRIVE ACCEL 3.0s
