JLG 4394RT - Machine Model Adjustment

SECTION 5 - JLG CONTROL SYSTEM
3121642 – JLG Lift – 5-25
Table 5-5. Machine Model Adjustment
Adjustment Adjustment Range
Model Default Values
3394RT 2WD 3394RT 4WD 4394RT 2WD 4394RT 4WD
DRIVE
Accel 0.1 - 5.0 (sec) 3 3 3 3
Decel 0.1 - 3.0 (sec) 1.2 1.2 1.2 1.2
Min Forward 0 - 35% 24 24 24 24
Max Forward 0 -100% 56 56 56 56
Min Reverse 0 - 35% 24 24 24 24
Max Reverse 0 -100% 55 55 55 55
Elev Fwd Max 20 - 50% 41 41 41 41
Elev Rev Max 21 - 50% 41 41 41 41
Engine 800 - 2900RPM 2800 2800 2800 2800
Mid Engine 800 - 2700RPM 2000 2000 2000 2000
LIFT
Accel 0.1 - 5.0 (sec) 2 2 2 2
Decel 0.8 - 1.5 (sec) 1 1 1 1
Min Up 0 - 35% 12 12 12 12
Max Up 0 - 65% 55 55 45 45
Min Down 0 - 35% 12 12 12 12
Max Down 0 - 65% 55 55 40 40
Engine 800 - 2900RPM 2800 2800 2800 2800
Mid Engine 800 - 2700RPM 2000 2000 2000 2000
STEER
Engine 800 - 2900RPM 2800 2800 2800 2800
POWER DECK
Deck Extend 800 - 2900RPM 1200 1200 1200 1200
Deck Retract 800 - 2900RPM 1200 1200 1200 1200
GROUND
Lift Up 0 - 65% 55 55 45 45
Lift Down 0 - 65% 55 55 40 40
LOAD
Overload
1000 - 2700 lbs
(454 - 1225 kg)
2475
(1123 kg)
2475
(1123 kg)
1650
(748 kg)
1650
(748 kg)
Acc’y
0 - 500 lbs
(0 - 227 kg)
0000
Overload Dbnce 0 - 10 (sec) 3 3 3 3
Overload Hold 1 - 10 (sec) 5 5 5 5
JOYSTICK
Forward Max 0.00 - 5.00V 0.75 0.75 0.75 0.75
Forward Min 0.00 - 5.00V 2.24 2.24 2.24 2.24
Reverse Min 0.00 - 5.00V 2.82 2.82 2.82 2.82
Reverse Max 0.00 - 5.00V 4.32 4.32 4.32 4.32
TEMP CUTOUT
Cutout Set -30 - 0 -30 -30 -30 -30
Offset 0 - 15 5 5 5 5
4150389 D
NOTE: These settings may be changed in order to achieve optimal performance.
