SECTION 5 - JLG CONTROL SYSTEM
5-10 – JLG Lift– 3121642
2/2
Flash code 2/2 indicates difficultly with the platform controls.
3
TRIGGER SWITCH WIRING SHORTED HIGH IN PLATFORM CABLE
Reports when the CAN message coming from the platform board and the DI on
ground board conflict.
TRIGGER SWITCH WIRING SHORTED LOW IN PLATFORM CABLE
Reports when the CAN message coming from the platform board and the DI on
ground board conflict.
FUNCTION LOCKED OUT – DRIVE SELECT PERMANENTLY CLOSED Reported when drive select is closed during power up.
FUNCTION LOCKED OUT – LIFT SELECT PERMANENTLY CLOSED Repor t ed wh en lift s ele c t i s c lo sed d urin g pow er up.
FUNCTION LOCKED OUT – FRONT DECK SELECT PERMANENTLY CLOSED Reported when front deck select is closed during power up.
FUNCTION LOCKED OUT – REAR DECK SELECT PERMANENTLY CLOSED Rep or te d w he n re ar de ck sele c t i s c los ed d uri ng p ow er up.
FUNCTION LOCKED OUT – START PERMANENTLY CLOSED Reported when the start switch is closed during power up.
FUNCTION LOCKED OUT – STEER LEFT PERMANENTLY CLOSED Reported when the left steer switch is closed during power up.
FUNCTION LOCKED OUT – STEER RIGHT PERMANENTLY CLOSED Reported when the right steer switch is closed during power up.
FUNCTION LOCKED OUT – AUX POWER SWITCH PERMANENTLY
CLOSED
Reported when the auxiliary switch is closed during power up.
FUNCTION LOCKED OUT – GENERATOR SWITCH PERMANENTLY
CLOSED
Reported when the generator switch is closed during power up.
FUNCTION LOCKED OUT – AUTOLEVEL SWITCH PERMANENTLY CLOSED Reported when the leveling jack se le c t s wi tc h i s c los ed dur ing p ow er up.
TRIGGER CLOSED TOO LONG WHILE IN NEUTRAL Reported when trigger is closed for ten seconds and no function selected.
FUNCTION LOCKED OUT – JOYSTICK NOT CENTERED Reported when joystick is not centered while selecting a function.
FUNCTION LOCKED OUT – TRIGGER SWITCH PERMANENTLY CLOSED Reported when the trigger switch is closed during power up.
JOYSTICK FAULTY – STEER SWITCHES ACTIVE TOGETHER Reported when both the left and right steer switches are closed at the same time.
FUNCTION LOCKED OUT – HORN SWITCH PERMANENTLY CLOSED Reported when the horn switch is closed during power up.
JOYSTICK CALIBRATION FAULTY Reported when joystick calibration is improper. (Platform P1.6 or later only)
Table 5-2. Fault Code Listing - Software P1.X
Fault Flash
Code
Communicated (Displayed on Analyzer) Fault Description Priority
