SECTION 5 - JLG CONTROL SYSTEM
3121642 – JLG Lift – 5-13
2/6
Flash code 2/6 indicates leveling jack or power deck issues.
6
FRONT LEFT LEVELING JACK OPEN CIRCUIT
Reported by the I/O module and during system test when the front left leveling
jack is open circuit.
FRONT LEFT LEVELING JACK SHORT TO GROUND
Reported by the I/O module and during system test when the front left leveling
jack i s sho r t to gr ou nd.
FRONT LEFT LEVELING JACK SHORT TO BATTERY
Reported by the I/O module and during system test when the front left leveling
jack is short to battery.
FRONT RIGHT LEVELING JACK OPEN CIRCUIT
Reported by the I/O module and during system test when the front right leveling
jack is open circuit.
FRONT RIGHT LEVELING JACK SHORT TO GROUND
Reported by the I/O module and during system test when the front right leveling
jack i s sho r t to gr ou nd.
FRONT RIGHT LEVELING JACK SHORT TO BATTERY
Reported by the I/O module and during system test when the front right leveling
jack is short to battery.
REAR LEFT LEVELING JACK OPEN CIRCUIT
Reported by the I/O module and during system test when the rear left leveling
jack is open circuit.
REAR LEFT LEVELING JACK SHORT TO GROUND
Reported by the I/O module and during system test when the rear left leveling
jack i s sho r t to gr ou nd.
REAR LEFT LEVELING JACK SHORT TO BATTERY
Reported by the I/O module and during system test when the rear left leveling
jack is short to battery.
REAR RIGHT LEVELING JACK OPEN CIRCUIT
Reported by the I/O module and during system test when the rear right leveling
jack is open circuit.
REAR RIGHT LEVELING JACK SHORT TO GROUND
Reported by the I/O module and during system test when the rear right leveling
jack i s sho r t to gr ou nd.
REAR RIGHT LEVELING JACK SHORT TO BATTERY
Reported by the I/O module and during system test when the rear right leveling
jack is short to battery.
LEVELING JACK EXTEND VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the leveling jack extend
valve is open circuit.
LEVELING JACK EXTEND VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the leveling jack extend
valve is short to ground.
LEVELING JACK EXTEND VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the leveling jack extend
valve is short to battery.
LEVELING JACK RETRACT VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the leveling jack retract
valve is open circuit.
LEVELING JACK RETRACT VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the leveling jack retract
valve is short to ground.
LEVELING JACK RETRACT VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the leveling jack retract
valve is short to battery.
FRONT DECK EXTEND VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the front deck extend
valve is open circuit.
FRONT DECK EXTEND VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the front deck extend
valve is short to ground.
FRONT DECK EXTEND VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the front deck extend
valve is short to battery.
FRONT DECK RETRACT VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the front deck retract
valve is open circuit.
Table 5-2. Fault Code Listing - Software P1.X
Fault Flash
Code
Communicated (Displayed on Analyzer) Fault Description Priority
