SECTION 5 - JLG CONTROL SYSTEM
5-16 – JLG Lift– 3121642
ACCESS LEVEL: CODE 33271 MENU: ACCESS LEVEL 1 MENU: PERSONALITIES
ACCESS LEVEL: CODE 00000
PERSONALITIES: DRIVE DRIVE: ACCEL X.X S DRIVE: DECEL X.X S DRIVE: MIN FORWARD X% DRIVE: MAX FORWARD X% DRIVE: MIN REVERSE X% DRIVE: MAX REVERSE X% DRIVE: ELEV FWD MAX XX% DRIVE: ELEV REV MAX XX% DRIVE: ENGINE XXXXRPM DRIVE: MID ENG XXXXRPM
PERSONALITIES: LIFT
LIFT: ACCEL X.X S LIFT: DECEL X.X S LIFT: MIN UP X% LIFT: MAX UP X% LIFT: MIN DOWN X% LIFT: MAX DOWN X% LIFT: ENGINE XXXXRPM LIFT: MID ENG XXXXRPM
PERSONALITIES: STEER STEER: ENGINE XXXX RPM
PERSONALITIES: POWER DECK DECK EXTEND: ENGINE XXXX RPM DECK RETRACT: ENGINE XXXX RPM
PERSONALITIES: GROUND MODE GROUND MODE: LIFT UP X% GROUND MODE: LIFT DN X%
PERSONALITIES: LOAD LOAD: OVERLD XXXX KG LOAD: ACC’Y XX KG LOAD: OVR DBNCE X.XS LOAD: OVR HOLD X.XS
PERSONALITIES: JOYSTICK JOYSTICK: FWD MAX X.XX V JOYSTICK: FWD MIN X.XX V JOYSTICK: REV MIN X.XX
V
JOY
S
T
I
C
K
:
REV
M
A
X
X
.
X
X
V
CONT’D ON SHEET 2
4170014_20
Figure 5-6. Analyzer Flow Chart - SW P1.X - Sheet 1 of 3
